Specifications
WhiteBalanceBrightness600 cd/m²
| PP-SD-P12C64 | PP-SD-P15C64 | PP-SD-P18C64 | PP-SD-P25C64 | |
| Pixel Configuration | SMD LED | |||
| Pixel Pitch | 1.25 | 1.53 | 1.86 | 2.5 |
| Cabinet Dimension (W × H × D, mm) | 640 × 480 × 59 | |||
| Cabinet Resolution (W × H) | 512 x 384 | 416 x 312 | 344 x 258 | 256 x 192 |
| Cabinet Weight | 8 kg | |||
| Cabinet Material | Aluminium die casting | |||
| Maintenance Method | Complete pre maintenance | |||
| White Balance Brightness | 600 cd/m² | |||
| Contrast | 5,000 : 1 | |||
| Color Temerature | 8,000 K adjustable | |||
| Viewing Angle | 160° (H)/160° (V) | |||
| Max. Consumption | 500 W/m² | |||
| Average Consumption | 150 W/m² | |||
| Refresh Rate | 3,840 Hz | |||
| Grey Level | Up to 14 bit | |||
